Sanitary ball valves

Item 610A

3-way sanitary ball valve, ISO direct mount, T/L-port, T-Clamp ends

• size: 1/2” to 2”
• mat: CF8M
• rating: 1000 WOG
• option: automation
  (learn more)

Item 620A

3/4-way sanitary ball valve, block type, ISO direct mount, T-Clamp/ tube end

• size: 1/2” to 4”
• mat: CF8M
• rating: 800 WOG
• option: automation, filler
  (learn more)

Item 302S

3-pc sanitary ball valve, ISO direct mount, T-Clamp/ tube end, extended tube weld

• size: 1/2” to 4”
• mat: CF8M, CF3M, Hastelloy C-22
• rating: 800 WOG
• option: automation/ BPE
  (learn more)

3-A Sanitary Standard 68-00 Certificied on 302S & 620A

In order to provide advanced hygienic ball valves for customers, Zipson apply the 3-A Sanitary Standard and certified before the end of 2017.

Pass Regulation (EC) No. 1935/2004Resolution CM/Res (2013)9, LFGB Section 30 & 31; (EU) 10/2011

How to order the 3-A Sanitary Standard Valves

The cerfified items are 302S, 3-pc sanitary and 620A, multi-way sanitary ball valves. These 2 items with 3-A standard design are for food, beverage, and pharmaceutical industries. The materials can be CF8M (SS316), CF3M (SS316L), AL6XN, CX2MW (Hastelloy C-22) for options. Just order the item, material, and state the valves are 3-A requested, Zipson will provide the valves with 3-A Sanitary designed.

Various end connection types

Zipson provide various end type for sanitary valves, it can be Tri-Clamp, Tube, Extended Tube, SMS 3008, DIN 32676.

Low Ferrite content valve

For some pharmaceutical equipments, the valve ask Low Ferrite content, less than 3% or 1%. Zipson can provide the valve casting with Low Ferrite content less than 1% for these pharma industries.
